Drive Class Change Sounders Or Bell Circuits Directly From The Class Change Controller.
Up to 20 Class Change Alarms Per Day.
The FASE/701/EXT/HP class change controller features internal high-power relays, allowing it to directly power and control 24V circuits of class change sounders or class change bells, such as the FASE/CC/SND or FASE/24/BELL. This creates a fully independent class change system with selectable electronic tones when used with the FASE/CC/SND class change sounder.
The controller offers the ability to programme up to 20 class change alarm times per day and includes highly configurable output ringing styles programmable in 1 second increments. Our FASE/701 range of class change time clocks offer everything needed to provide class change indications in schools, colleges or factories.
Fase Controls Takes Class Change Time Clocks To A Whole New Level With Our Range Of Incredibly Advanced Class Change Timer And School Bell System Controllers
Fase Controls offers complete class change systems. By using the FASE/CC/SND class change sounders or the FASE/24/BELL class change bell with a FASE/701/EXT/HP or FASE/701/EXT/HP class change controller, you can create truly independent class change systems.
The FASE/701/EXT/HP class change time clock contains internal power relays capable of switching up to 6 amps per circut at 24VDC, allowing dedicated class change sounders or bells to be wired directly from the class change controller itself.
With a simple to navigate, yet comprehensive menu structure, the FASE/701/EXT/HP class change timer has been designed to be as user-friendly as possible and the simple programming options offered to the engineer help reduce installation & configuration times.
The FASE/701/EXT/HP Class Change Timer will allow up to 20 individual class change times per day to be programmed. The 'Copy Alarms' feature lets the installation engineer set the required class change alarms for Monday and then copy these to all school days (Mon-Fri) or all days (Mon-Sun). All of which can then be edited as required. This not only makes programming the class change times simple, but it also frees up the installation engineer for other tasks.
Drive Circuits Of Sounders Or Bells Directly From The Class Change Controller
The FASE/701/EXT/HP comes equipped with internal, high-power relays designed to efficiently switch dedicated class change sounder circuits, allowing for the installation of a completely independent class change system.
With two output relays, each rated at a maximum of 6 amps per circuit, the FASE/701/EXT/HP has the capacity to drive up to 64 FASE/CC/SND sounders or 48 FASE/24/BELL class change bells per circuit.
Electronic Sounders For Class Change Indication
Fase Controls offers complete class change systems. The FASE/CC/SND sounders, designed for use with the FASE/701/EXT/HP class change controller, create a fully independent class change solution.
These class change sounders are installed directly onto the class change circuit and utilise innovative piezoelectric technology to provide selectable tones.
With typical current draw as low as 5.5mA, the FASE/CC/SND sounder is a truly cost-effective solution. It also issues 360-degree sound output at up to an impressive 96dB(A) sound output @ 1m, ensuring clear notification of the class change alarm.
The motorised bell needs no intruduction due to its historic use with fire alarm systems and the older generation of class change and school bell systems.
The FASE/701/EXT/HP has been specifically designed to drive the FASE/24/BELL to provide class change indication and is capable of drving upto 48 class change bells per circuit.
Simply wire sounder circuits from a FASE/700/HP/B unit to add an additional 2 circuits per 700/HP/B controller.
Having trigger in & out terminals, several FASE/700/HP/B units can be daisy-chained together to supply the number of sounder circuits required.
FASE/700/HP/B Controller - COMING SOON
Simple To Install, Programme & Maintain
Designed to be a class change time clock from the outset, the FASE/701/EXT/HP class change timer switches a set of high-power, clean relay contacts at programmable times of the day to power dedicated class change sounder circuits.
FASE/CC/SND electronic class change sounders or FASE/24/BELL class change bells are then wired from the controller on circuits routed through the premises with the sounders/bells themselves positioned at strategic positions to give the best sound coverage.
The duration of the alarm can be programmed to ring for the desired period, adjustable in 1-second increments.
DESIGNED & MANUFACTURED IN THE UK
Fase/701/EXT/HP
50 Items
Data sheet
Model
FASE/701/EXT/LP
SKU
701EXTLP
For Use With Sounders Or Bells
For Use With Electronic Sounders
Range
'HP' Range
Signalling Type
Signal With Sounders
Class Change Alarms Per Day
Upto 60 Alarms Per Day
Max Output Current
< 65ma With All Outputs Energised & LCD Back Light @ 100%
Features
Class Change Time Clock
Directly Power and Control 24V Sounder Circuits
Enclosure Size
Deep Enclosure: 170 x 85.5 x 60.5mm (L x H x D)
LCD Technology
1.54" TFT IPS LCD Display With 240x240px resolution
Enclosure Colour
Off-White
Legend Colour
White Background with Dark Grey Print
Base Material
Plastic
Material Type
ABS UL94-V0
UL Rating
UL94-V0
Operating Temperature
0°C to +40°C
IP Rating
IP40
Supply Voltage
20-28VDC
Quiescent Current
< 25ma
Accuracy
Accuracy Upto ±5ppm from 0°C to +40°C
Output Technology
2x Power Relays Rated 5amps @ 30VDC
Full Colour TFT Display
Internal Buzzer
Memory Technology
EEprom Memory & Super Capacitor (No Coin Cell Required)
Fire Alarm Connection Details
Dependant On The System which Is Being Connected To
Reviews can be placed by customers that purchased this product
Drive Class Change Sounders Or Bell Circuits Directly From The Class Change Controller.
Up to 20 Class Change Alarms Per Day.
The FASE/701/EXT/HP class change controller features internal high-power relays, allowing it to directly power and control 24V circuits of class change sounders or class change bells, such as the FASE/CC/SND or FASE/24/BELL. This creates a fully independent class change system with selectable electronic tones when used with the FASE/CC/SND class change sounder.
The controller offers the ability to programme up to 20 class change alarm times per day and includes highly configurable output ringing styles programmable in 1 second increments. Our FASE/701 range of class change time clocks offer everything needed to provide class change indications in schools, colleges or factories.
Supplied in the deep enclosure.
